Lichtenberger Engineering Library

Tool Library

Circulation policies

Question? Ask Kari Kozak!

3D Scanners
Return to top of page

3D Scanner: Sense

 Included:

  • 1 Scanner

Driver and User manual found here

Rapidly archive and preserve artifacts, products and items as color 3D data and scan objects to begin design for 3D gaming applications. Market your products by using 3D scan data in online catalogs and visualizations for marketing. Post 3D scans to share with your peers or customers directly from the Sense software at SketchFab and Facebook.

Location: Engineering Circulation Desk

3D Scanner: Structure Sensor

Included:

  • 1 Sensor
  • 1 Attachment Cable
  • 1 Power Adapter
  • 1 Mini Screwdriver

When used as a 3D scanner, Structure Sensor allows you to capture dense geometry in real-time. This enables you to simulate real world physics and create high-fidelity 3D models with high-resolution textures in seconds. The possibilities are incredible.

App available in App Store

User manual found here

Location: Engineering Circulation Desk

3D Scanner: Xbox Kinect

Included:

  • 1 Kinect
  • 1 Computer Adapter (in 4 pieces)

Take advantage of Kinect’s advanced skeletal tracking, enhanced noise isolation, wider field of view, 1080p HD camera, precise gesture recognition, and low-light capabilities. Then publish your apps to the Windows Store.

Use the “3D Scan” app from the Windows App Store and a PC to create 3D Scans

Location: Engineering Circulation Desk

Cables
Return to top of page

30 Pin to VGA

30 Pin (Male) to VGA (Female)

Location: Engineering Circulation Desk

30 Pin Wall Charger

30 Pin Cable and Wall Adapter

Location: Engineering Circulation Desk

45 W MagSafe Power Adapter

MagSafe power cable for MacBook Air

Included: MagSafe to MagSafe2 Converter

Location: Engineering Circulation Desk

60 W MagSafe Power Adapter

MagSafe power cable for MacBook and 13 Inch MacBook Pro

Included: MagSafe to MagSafe2 Converter

Location: Engineering Circulation Desk

85 W MagSafe Power Adapter

MagSafe power cable for 15 and 17 Inch MacBook Pro

Included: MagSafe to MagSafe2 Converter

Location: Engineering Circulation Desk

Graphing Calculator Wall Charger

USB Mini – B Cable and Wall Adapter for graphing calculators

Location: Engineering Circulation Desk

HDMI to HDMI "HDMI Cable"

Male HDMI to Male HDMI aka “HDMI Cable”

Location: Engineering Circulation Desk

HDMI to Micro HDMI

Male Micro HDMI to Male HDMI

Location: Engineering Circulation Desk

HDMI to Mini HDMI

HDMI (Male) to Mini HDMI (Male)

Location: Engineering Circulation Desk

HDMI to VGA

HDMI (Male) to VGA (Female)

Location: Engineering Circulation Desk

Lightning to HDMI

Lightning (Male) to HDMI (Female)

Location: Engineering Circulation Desk

Lightning to VGA

Lightning (Male) to VGA (Female)

Location: Engineering Circulation Desk

Lightning Wall Charger

Lightning Cable and Wall Adapter

Location: Engineering Circulation Desk

Micro USB Wall Charger

Micro USB Cable and Wall Adapter

Location: Engineering Circulation Desk

MiniDisplay Port to HDMI

MiniDisplay Port (Male) to HDMI (Female)

Location: Engineering Circulation Desk

MiniDisplay Port to VGA

MiniDisplay Port (Male) to VGA (Female)

Location: Engineering Circulation Desk

Surface Charger

Surface Charging Cable for Microsoft Surface Devices

Location: Engineering Circulation Desk

Targus Laptop Charger

AC Adapter, Wall Adapter, Fast USB Port, 12 Charging Tips for Laptops and Portable Devices

Location: Engineering Circulation Desk

USB Cable Extension

Female USB to Male USB

10 Feet Long

Location: Engineering Circulation Desk

USB-A to USB-B

Male USB-A to Male USB-B

Location: Engineering Circulation Desk

USB-C to HDMI

Male USB-C to Female HDMI

Location: Engineering Circulation Desk

USB-C to USB

Male USB-C to Female USB

Location: Engineering Circulation Desk

USB-C to USB Cable

Male USB-C to Male USB

Location: Engineering Circulation Desk

USB-C Wall Charger

USB-C Cable and Wall Adapter

Location: Engineering Circulation Desk

Cameras
Return to top of page

Camera: 360fly 360 Degree

Included:

  • 1 Camera
  • 1 Sleeve
  • 1 Charging Cable,
  • 1 Charging Cradle,
  • 1 Action Camera Adapter

App required for use download from App Store or Google Play

Life doesn’t just come at you straight on. Which is why the 360fly 4K and 360fly HD puts you in the center of the action while capturing the entire world around you.

Dustproof and Shock Proof

360 Degree Video or Standard 4k Video Recording

Full user Android and iOS manual found here.

Location: Engineering Circulation Desk

Camera: Canon PowerShot

Included:

  • 1 Camera
  • 1 Lens Cap
  • 1 Camera Strap
  • 2 Batteries
  • 1 Battery Charger
  • 1 32 GB SD Card
  • 1 SD Card Reader with caps
  • 1 Case and Strap
  • 1 Tripod
  • 1 Lens Cleaning Kit

Whether the perfect shot is up close or seemingly out of reach, you’ll capture it beautifully thanks to the amazing 50x (24-1200mm) zoom power of the PowerShot SX530 HS camera.

Location: Engineering Circulation Desk

Camera: GoPro

Included:

  • GoPro Hero 5
  • Mounting Frame
  • Super Suit
  • Aluminium Case
  • Skeleton Backdoor
  • Mounting Bracket
  • Mounting Screw
  • USB Charging  Cable
  • 2 Batteries
  • 32GB Micro SD Card
  • Micro SD Card Adapter
  • Micro SD/SD Card Reader
  • Chest Harness
  • Head Strap Mount
  • Mini Tripod
  • Hand Monopod
  • Floating Handle Grip

HERO5 Black is the most powerful and easy to use GoPro ever, thanks to its 4K video, voice control, one-button simplicity, touch display and waterproof design.

Manual can be found at: https://goo.gl/nnUGe4



Location: Engineering Circulation Desk

Camera: Sports Camcorder

Included:

  • Camcorder
  • Battery
  • Power Adapter
  • AV Cable
  • USB Cable
  • External Camera
  • Camera Mount
  • Mount Band
  • Carrying Case
  • 1gb SD Card
  • SD Card Reader and Cable

The SC-X300 camcorder lets you capture the action. A 10x optical/100x digital zoom, 680K-pixel CCD and electronic image stabilization deliver crisp visuals, while you also enjoy the convenience of MP3, webcam, voice recorder, and data storage functions.

Manual can be found at: https://goo.gl/YrRCfI



Location: Engineering Circulation Desk

Camera: Theta S 360 Degree

Included:

  • 1 Camera
  • 1 Sleeve
  • 1 Charging/Transfer Cable

Beauty as far as the eye can see, and a breathtaking sense of presence making you feel you are “right there, right now”. From still images to long movies (max. 25 minutes long),     record your memories in a vivid, high resolution 360° world.

App available for Android an iOS to record video and still photography

Use a computer to Live Stream

User manual found here

Location: Engineering Circulation Desk

Camera: Webcam

  • Includes: 1 eyeball camera, 1 base, 1 9 inch stand
  • Megapixel: 8 MP
  • Maximum video resolution: 1600 x 1200 pixels
  • Maximum frame rate: 30 fps
  • Interface: USB
  • Minimum processor: Pentium 4
  • Minimum RAM: 128 MB
  • Minimum hard disk space: 200 MB

Tool Sponsor: Engineering Computer Services

Location: Engineering Circulation Desk

Computer Accessories
Return to top of page

Computer Microphone

  • Includes:1 Microphone
  • Automatic electronic steering of “listening beam” to talker location and two stage noise reduction (spatial filtering and noise reduction processing)
  • Mute mode
  • 5 element “in range” light to indicate location of chosen talker and sufficiency of signal

Tool Sponsor: Engineering Computer Services

Location: Engineering Circulation Desk

Computer Mouse

Plug-and-Play wired computer mouse

USB compatible

Location: Engineering Circulation Desk

Draw Pen

Included:

  • 1 Pen

Intuos Pen is used with the Intuos Draw Tablets

Location: Engineering Circulation Desk

Draw Tablet

Included:

  • 1 Tablet
  • 1 Pen
  • 1 USB Cable

Must download driver to use. Download here

Unleash your creativity with the new Intuos. It includes Wacom’s leading pen & touch tablet technology

Getting started manual located here

Location: Engineering Circulation Desk

Projector 1

Included:

  • Projector
  • Power Cable
  • VGA/VGA Cable
  • Yellow Video Cable
  • Red/White RCA to Mini Headphone Jack Cable
  • Mini  Headphone Jack Cable “Aux Cord”
  • Remote
  • Owners Manual

NEED TO CONVERT FROM VGA

Dell MP4100



Location: Engineering Circulation Desk

Projector 2

Included:

  • Projector
  • Power Cable
  • VGA/VGA Cable
  • 2 Remotes
  • Owners Manual

NEED TO CONVERT FROM VGA

Toshiba TDP-T98

Location: Engineering Circulation Desk

Projector 3

Included:

  • Projector,
  • Power Cable,
  • VGA/VGA Cable,
  • Owners Manual

NEED TO CONVERT FROM VGA

Sharp XG-MB70X

Location: Engineering Circulation Desk

Wireless Presenter

Includes:

  • Device
  • Receiver
  • Bag
  • Manual

A plug-and-play wireless presentation device

Wireless remote control distance range of up to 39-feet

Note: Check for receiver under battery cover before returning

Location: Engineering Circulation Desk

Hand Tools
Return to top of page

Hammer

  • Claw Hammer
  • 16oz

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

Heat Gun Kit

Included:

  • Heat Gun
  • Fan Nozzle
  • Glass Protector
  • Cone Nozzle
  • Spool Reflector
  • Handheld Scraper

This heat gun can be used for many different applications. It has a powerful 12.5 AMP/1500 Watt motor as well as dual fan speed. High level of control using the continuous adjustable temperature, and take advantage of the integrated support stand.

Safety:

  • Not for use in library
  • Do not put back in box while hot

User Manual found here



Location: Engineering Circulation Desk

Hex Key: Folding, Metric

  • 17 inch

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Hex Key: Folding, SAE

  • 17 inch

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Hex Key: T-Handle, Metric

Includes:

  • 1 Steel Index Stand
  • 10 Metric Wrenches: 2 mm, 2.5 mm, 3 mm, 4 mm, 4.5 mm, 5 mm, 5.5 mm, 6 mm, 8 mm, 10 mm

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Hex Key: T-Handle, SAE

Includes:

1 Steel Index Stand

10 wrenches: 3/32″ 7/64″ 1/8″ 9/64″ 5/32″ 3/16″ 7/32″ 1/4″ 5/16″ 3/8″

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Hot Glue Gun

Product Features:

  • 80 watt glue gun

Safety

  • Do not put back in box while hot
  • Materials available from Electronics Shop
Location: Engineering Circulation Desk

Pliers: 2-Piece Set

Includes

  • 6” Slip Joint Pliers
  • 6” Long Nose Pliers

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

Pliers: 4-Piece Set

Includes:

  • 8-inch slip joint
  • 7-inch diagonal
  • 8-inch lineman
  • 8-inch long nose

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Pliers: 6-Piece Mini Set

Includes

  • Diagonal Cutting Plier
  • Groove Joint Plier
  • End Cutting Plier
  • Bent Long Nose Plier
  • Long Nose Plier
  • Flat Nose Plier

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

Pliers: Diagonal

  • 1 pair of pliers

Tool Sponsor: Engineering Technology Centers

Location: Engineering Circulation Desk

Screwdriver: 7-Piece Set

Includes: two cabinet-tip; three Phillips-tip; two keystone-tip screwdrivers

  • JSD
  • 4C06
  • JSD6C06
  • JSD4K08
  • JSD6K09
  • JSD4PH1
  • JSD4PH2
  • JSD6PH3

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Screwdriver: Computer Toolkit

Includes

  • 2 straight Blades 1.8mm, 3.0mm
  • 2 Phillips #00,  #2
  • 3 Torx T6, T8, T10
  • 1 scissor clamp tweezers
  • 1 nylon pry tools (aka “spudgers”)

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Screwdriver: Mini 6-Piece Set

Includes:

  • Slotted – 1.5mm, 2.0mm, 2.5mm
  • Phillips – #00, #0, and #1 packaged in a case

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Screwdriver: Mini Torx Set

Includes:

  • T-5
  • T-6
  • T-7
  • T-8
  • T-9
  • T-10

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Screwdriver: Security Bits Set

Includes:

  • 1 standard bit holding handle
  • 1 standard 1/4″ magnetic bit holder
  • 1 1/4″ drive bit holding socket adapter
  • 8 tamper resistant Torx: T8, T10, T15, T20, T25, T27, T30, T40
  • 4 tri-wings: 1, 2, 3, 4
  • 3 Torq: 6, 8, 10
  • 4 Spanner: 4, 6, 8, 10
  • 6 Tamper resistant hex: 5/64″, 3/32″, 7/64″ 1/8″, 9/64″, 5/32″
  • 2 slotted: 6.5mm, 8.0mm
  • 2 Phillips:, 2, 2
  • 4 Pozidriv: 0, 1, 2, 3
  • 2 Square: 1, 2, 3

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Screwdriver: Video Game Set

Includes 28 piece bits for:

  • Microsoft: XBox, XBox 36
  • Sega: Saturn, Game Gear, Dreamcast, Genesis
  • Nintendo: Wii, Gameboy, Advance (GBA), DS & DS Lite, NES, Super NES (SNES), Nintendo 64 (N64)
  • Sony: Playstation (PS),  Playstation 2 (PS2),  Playstation 3 (PS3), Playstation Portable (PSP)

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Sheet Metal Hole Punch

Included:

  • Hole Punch
  • Key
  • 7 Pairs of Punch and Dies
  • Instruction Manual

Punches and Die Sets:

  • 3/32
  • 1/8,
  • 5/32
  • 3/16
  • 7/32
  • 1/4
  • 9/32



Location: Engineering Circulation Desk

Socket Set

Standard and Metric, 60-Pieces

Includes:

  • 24 1/4-inch sockets
  • 19 3/8-inch sockets
  • 1 3/8-inch pear head ratchet arm
  • 1 1/4-inch socket driver handle
  • 1 3/8- to 1/4-inch adapter
  • 1 3/8-inch extension bar
  • 1 1/4-inch drive specialty bit holder
  • 10 specialty bits
  • blow molded case
  • color graphic labels

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Soldering Iron

Product Features:

  • Variable power control built into station
  • Safety guard iron holder
  • Natural sponge tip cleaning pad
  • Desoldering Pump and Solder Wick included

Safety

  • Not for use in library
  • Do not put back in box while hot
  • Materials and training available from Electronics Shop



Location: Engineering Circulation Desk

Wire Cutter/Stripper

  • 1 cutter/stripper

Tool Sponsor: Engineering Technology Centers

Location: Engineering Circulation Desk

Wrench Set

Includes:

  • 10 SAE Wrenches: 1/4-in 5/16-in 3/8-in 7/16-in 1/2-in 9/16-in 5/8-in 11/16-in  3/4-in 7/8-in
  • 10 Metric Wrenches: 8 mm, 9 mm, 10 mm, 11 mm, 12 mm, 13 mm, 14 mm, 15 mm, 17 mm, 18 mm

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Wrench: Adjustable

  • Laser-marked SAE and metric jaw scale
  • Forged alloy-steel body
  • Extra-wide jaw capacity
  • Bi-material handle
  • Used for automotive maintenance and repair, plumbing and general assembly tasks

Location:

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

LabQuest
Return to top of page

LabQuest

To be used with LABQUEST Accessories

  • Includes:
    • (1) rechargeable battery
    • (1) power adapter
    • (1) USB cable
    • (1) stylus
    • (1) stylus tether
  • Device used to collect data in experiments using LABQUEST accessories.
  • Contains internal sensors including GPS, accelerometers, temperature, light sensor, and microphone

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest 3-Axis Accelerometer

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Consists of three –5 to +5 g accelerometers mounted in one small block.
  • Able to graph any of these components or calculate the magnitude of the net acceleration.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest CO2 Gas Sensor

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Includes:
    • (1) CO2 Gas Sensor
    • (1) 250 mL gas sampling bottle (Nalgene bottle with lid)
    • (1) CO2  Gas Sensor Manual
  • The Vernier CO2 Gas Sensor measures gaseous carbon dioxide levels by monitoring the amount of infrared radiation absorbed by carbon dioxide molecules.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Dual Range Force Sensor

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Includes:
    • (1) black screw
    • (1) bumper
    • (1) utility handle
    • (1) hook
  • For measuring pushing and pulling forces in a variety of experiments.
  • Measures forces from 0.01 to 50 Newtons.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest EKG Sensor

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Measures electrical potential waveforms (voltages produced during the contraction of the muscle).
  • Monitor EKG, study the meaning of P, Q, R, S, and T waveforms, determine the axis of the heart, investigate the effect of the central nervous system influence on reflex amplitude, and associate the electrical activity of a muscle with movement of joints.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Electrode Amplifier

To be used with LABQUEST Data Collector Device

Product Description:

  • Can produce an output in mV, pH (when using a pH electrode), or you can perform your own 2-point, linear calibration.
  • Amplifies the voltage produced by an electrode into a range where it can be monitored by the lab interface.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Force Plate

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Includes: (2) handles
  • Can measure the forces developed during stepping, jumping, and other human-scale actions.
  • With handles in place, you can support the unit by hand for pushing on a wall or other large object, or you can attach an optional second pair of handles for pulling experiments.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Gas Pressure Sensor

To be used with LABQUEST Data Collector Device

Included:

  • Sensor
  • Syringe
  • 2 Stoppers
  • 2 Tubing Clamps

Used to monitor pressure changes in a gas

The range is wide enough to perform Boyle’s law yet it is sensitive enough to conduct vapor-pressure or pressure-temperature       experiments



Location: Engineering Circulation Desk

LabQuest Go!Motion

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Includes: (1) USB cable
  • Used to collect position, velocity, and acceleration data of moving objects
  • Range of 0.15 to 6 meters.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Goniometer

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Includes:
    • (1) 12-inch flexible joint arm
    • (1) 10-inch flexible joint arm
    • (1) 8-inch flexible joint arm
    • (2) 24-inch elastic hook and loop straps
    • (2) 14-inch elastic hook and loop straps
  • Measures the angle of a joint, such as the knee or elbow.
  • A set of elastic straps can be used to secure the sensor to the subject for dynamic measurements of joint angle during different types of physical activity.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Instrumentation Amplifier

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Provides the necessary gain and offset to allow you to connect a wide variety of measurement equipment to your interface and electronically collect, store, and analyze the data.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Low-g Accelerometer

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Measures acceleration along the line marked by the arrow on the label
  • Accelerations are normally measured in either meters per second per second (m/s2) or g’s.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Magnetic Field Sensor

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Measures a vector component of the magnetic field near the sensor tip.
  • The tip can be adjusted, allowing the user to measure fields that are parallel or perpendicular to the long axis of the sensor.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Microphone

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Used for a variety of activities with sound waves.
  • Frequency range is approximately 100 Hz to 15 kHz.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest pH Sensor

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Includes:
    • (1) pH Sensor
    • (1) Electrode Storage bottle containing pH 4/KC1 solution
    • (1) User Manual
  • Use the pH Sensor just as you would a traditional pH meter with the additional advantages of automated data collection, graphing, and data analysis. Typical activities using a pH sensor include:
    • Acid-base titrations
    • Studies of household acids and bases
    • Monitoring pH change during chemical reactions or in an aquarium as a result of photosynthesis
    • Investigations of acid rain and buffering
    • Analysis of water quality in streams and lakes

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Power Amplifier

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Includes:
    • (1) female power adapter
    • (1) male power adapter cord
    • (1) Audio/LabQuest cable
    • (1) current sense
    • (1) LabPro input cable
  • Allows drive loads with ±10 V and currents up to 1 A.
  • Works with any input waveform.
  • Can drive a variety of loads, such as speakers, lamps, small DC motors, and RLC circuits. These circuits typically draw more power than the signal source can deliver.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Rotary Motion Sensor

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Includes: (1) thumb screw, (1) 3-step pulley and mounting screw, (1) O-ring, and (1) sensor clip
  • A bidirectional angle sensor designed to measure rotational or linear position, velocity, and acceleration.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Salinity Sensor

To be used with LABQUEST Data Collector Device

Included:

  • Sensor

The Salinity Sensor easily and precisely measures the total dissolved salt content in an aqueous solution. Measure water with a wide variety of salinities, from brackish water to ocean water, and even hyper-saline environments. You can also study how salinity affects buoyancy or monitor salinity values in estuaries where fresh water mixes with ocean water.

Location: Engineering Circulation Desk

LabQuest Sound Level Meter

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Includes:
    • (1) sound level meter cable
    • (1) Wind screen (black foam cover for the sensing element)
  • Measures sound level in decibels.
  • Measurement range:
    • Low: 35 dB to 90 dB
    • High: 75 dB to 130 dB

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Surface Temperature Sensor

To be used with LABQUEST Data Collector Device

Product Description:

  • Designed for use in situations in which low thermal mass or flexibility is required
  • Temperature range: –25 to 125°C (–13 to 257°F)

Warning: The Surface Temperature Sensor is for use in air and water only.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Temperature Probe

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Typical uses include heat of fusion experiments, weather studies monitoring endothermic exothermic reactions, specific heat experiments, and insulation studies.
  • Temperature range: –40 to 135°C (–40 to 275°F)

Warning: Do not completely submerge the sensor. The handle is not waterproof.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Thermocouple

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • A simple and rugged sensor designed to measure temperature in the range of –200°C to 1400°C.
  • This sensor could be used to study how the temperature inside a Bunsen burner flame varies with position, compare the temperatures of different flames (candles vs. Bunsen burner), check the calibration of ovens, experimentally determine the melting point of copper, bismuth, or other solids; or measure the temperature of dry ice or liquid air.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Watts Up Pro

To be used with LABQUEST 2 Data Collector Device

Product Description:

Watts Up Pro calculates a wide variety of data, including maximum watts, frequency, and cumulative costs. Logger Pro collects data on the following types of data simultaneously:

  • Real Power: The power currently being consumed by the device that is plugged into Watts Up Pro, measured in watts.
  • Potential: The root mean squared (RMS) potential present on the power line.
  • Current: The RMS current being drawn by the device that is plugged into Watts Up Pro, measured in amperes.
  • Apparent Power: The product of the RMS potential and the RMS current.

Only use the included blue USB cable with the Watts Up Pro.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

LabQuest Wireless Dynamics Sensor System

To be used with LABQUEST 2 Data Collector Device

Product Description:

  • Includes:
    • (1) power adapter
    • (1) black plastic plate
    • (2) hooks of varying sizes
    • (1) metal screw extension
    • (1) bumper
    • (5) screws of varying sizes and shapes
    • (1) silver metal rod with eyelet
  • Allows you to take data from a three-axis accelerometer, force sensor, and altimeter, using a Bluetooth® wireless connection to your computer

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

Measuring Tools
Return to top of page

Angle Locator

  • Magnetic Angle Locator
  • High Impact Body In Hi Visibility Orange
  • 90 Degrees In 4 Quadrants Grooved Edge
  • Metric Rule On 1 Edge & English Rule On The Other

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Caliper

  • Resolution: 0.01mm/0.0005 inch
  • Accuracy: 0.02mm/0.001 inch

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Environmental Meter

  • Anemometer uses a low-friction ball bearing mounted wheel design for high accuracy.
  • Humidity meter uses a high precision humidity sensor for fast response time.
  • Light meter uses a photo diode and color correction filter light sensor; spectrum meets C.I.E. photopic.
  • Type K thermometer uses standard type K (NiCr-NiAl) thermocouple input jack suitable for diverse application type K probes.
  • Sound level meter meets IEC 61672 class 2 with “A” frequency weighting and “Fast” time response.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

Laser Distance Measurer

  • Range 100′ (30m) Accuracy +/- 3/22″ (2mm)
  • Meaures Distance, Caluclates Area & Volume
  • Automatic caluculations make job estimates quick & easy
  • Continuous Measurement Tracking Function
  • Finds distance from a target quickly & easily
  • Addition/Subtraction. Convenient way to calculate in the field without a calculator or manual math

Tool Sponsor: Engineering Technology Centers

Location: Engineering Circulation Desk

Level

6″ level with magnetic strip

  • Heavy duty PVC construction
  • Magnetic strip for hands-free work
  • Can be used vertically, horizontally and at a 45° angle
Location: Engineering Circulation Desk

Light Meter

  • Measures In Lux and Foot Candles (User Selectable)
  • Long-Life Silicon Photo Diode Inside
  • Over-Range Indicator – Measurement Rate: 1.5 Times per Second – Dimensions: 6.50-Inch H x 2.99-Inch W x 1.69-Inch D
  • Auto Ranging – Max Range: 400,000 Lux – Weight: 14.22-Ounce
  • Peak Hold, Max and Data Hold – Accuracy: +/- 5-Percent Under 10000 Lux, +/- 10-Percent Over 10000 Lux
  • Relative Mode – Max Resolution: 0.1 Lux/FC

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Micrometer

  • 2 measuring modes Metric/Standard
  • Large LCD Display
  • Absolute & Incremental Modes
  • Automatic Switch Off
  • Accuracy +/- 0.00016″
  • Range 0-1″/0-25mm
  • Resolution 0.00005″/0.001mm
  • Direct RS232 SPS Output
  • Meet or Exceeds Federal Accuracy Standards

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Multimeter/Voltmeter

Calibrated Specifications Voltage DC Accuracy

  • ± (0.09%+2) Max. Resolution: 0.1 mV Maximum 1000 V Voltage AC Accuracy
  • ± (1.0%+3) Max. Resolution: 0.1 mV Maximum: 1000 V Current DC Accuracy
  • ± (1.0%+3) Max. Resolution: 0.01 mA Maximum: 10 A Current AC Accuracy
  • ± (1.5%+3) Max. Resolution: 0.01 mA Maximum: 10 A Resistance Accuracy
  • ± (0.9%+1) Max. Resolution: 0.1 ? Maximum: 50 M? Capacitance Accuracy
  • ± (1.2%+2) Max. Resolution: 1 nF Maximum: 10,000 °F Frequency Accuracy
  • ± (0.1%+1) Max. Resolution: 0.01 Hz Maximum: 100 kHz Temperature Accuracy
  • ± (1.0%+10) Max. Resolution: 0.1°C Range: -40°C/400°C

Note: Accuracies are best accuracies for each function Environmental Specifications Operating Temperature: -10°C to +50°C Storage Temperature: -30°C to +60°C Humidity (Without Condensation): 0% – 90% (0°C – 35°C) 0% – 70% (35°C -50°C) Safety Specifications Overvoltage category: EN 61010-1 to 1000 V CAT III. EN 61010-1 to 600 V CAT IV. Agency Approvals: UL, CSA, TUV listed and VDE Pending Mechanical & General Specifications.

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Oscilloscope

Included:

  • 1 Oscilloscope
  • 1 Power Cable
  • 2 Oscilloprobe

Key performance specifications

  • 40 MHz, 60 MHz, and 100 MHz bandwidths
  • Sample rates up to 1 GS/s real time

Key features

  • 2 channels
  • Monochrome LCD display
  • Advanced triggers including pulse width trigger and line-selectable video trigger
  • FFT standard on all models
  • 12 automatic measurements
  • Multiple-language user interface and context-sensitive help



Location: Engineering Circulation Desk

Power Monitor

  • Includes one Kill A Watt EZ Power Monitor P3
  • Shows the operating costs of your household appliances
  • Accurate to within 0.2%
  • Large LCD Display
  • Calculates cost and forecasts by week, month and year
  • Built-in battery backup
  • Displays eight critical units of measure (voltage, current, watts, kilowatt hours, frequency, volt amps, power factor, elapsed time

Tool Sponsor: Engineering Technology Centers

Location: Engineering Circulation Desk

Scale: Digital

  • Weight Capacity 5,000g
  • Units: g, ml, oz, lb’oz

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

Scale: Pocket Grain

  • Touchscreen scale with flip cover

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Scale: Triple Beam Balance

  • Readability: 0.1g
  • Stainless steel plate size: 6″ dial
  • Scale dimensions: 12″ W x 9″ H x 18″ D.
  • Front beam calibration: 10g x 0.1g
  • Middle beam calibration: 500g x 100g
  • Rear beam calibration: 100g x 10g

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Scale: Tubular Spring

Set of 4 dual mass spring scales to measure force (Newtons) and mass (grams).

  • 500gr – Green (Newton graduations begin at 0 and are marked at each .5″ increment up to “5”. Gram graduations begin at “0” and are marked at each “50” gram increment up to “500”.)
  • 1000gr – Brown (Newton graduations begin at 0 and are marked at each 1″ increment up to “10”. Gram graduations begin at “0” and are marked at each “100” gram increment up to 1000.)
  • 3000gr – White (Newton graduations begin at 0 and are marked at each 5″ increment up to “30”. Gram graduations begin at “0” and are marked at each “500” gram increment up to 3000.)
  • 5000gr – Yellow (Newton graduations begin at 0 and are marked at each 10″ increment up to “50”. Gram graduations begin at “0” and are marked at each “1000” gram increment up to 5000.)

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Sound Level Meter

  • USB interface with datalogging software
  • Internal datalogging of up to 20,000 records A and C weighting
  • Selectable fast / slow response time
  • Analog bargraph display
  • Large 1999 count backlit LCD display analog bargraph and numerous on-screen icons
  • USB interface with included cable and datalogging software
  • Included AC adaptor or battery operation
  • Selectable MIN or MAX hold and data hold function
  • Three measurement ranges
  • Threaded insert which accepts standard tripod mount
  • 0.1dB resolution
  • Selectable auto-power-off
  • Removable windscreen
  • Includes manual and 9V battery

Measurement ranges:

  • Low: 30 ~ 80dB
  • Medium: 50 ~ 100dB
  • High: 80 ~ 130dB
  • Auto: 30 ~ 130dB

Specifications:

  • Frequency range: 31.5Hz ~ 8KHz
  • Microphone element: 1/4″ electret condenser
  • Sample rate: 0.5 seconds
  • Time weighting: 125mS (fast), 1 Sec. (slow)
  • Accuracy: ±1.4dB @ 1KHz, 94dB
  • DC output: 10mV/dB, 1KΩ load
  • AC output: 1VRMS per each   range step, 100Ω load
  • Dimensions: 9¾” (L) x 2½” (W) x 1″ (D)

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Tachometer

  • RPM Range:2.5-99,999RPM
  • Takes Accurate RPM Measurements Without Touching Object
  • High Accuracy of .05%
  • Auto-Zero Adjustment
  • Detecting Distance: 50~500mm

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

Tape Measure

  • Self locking mechanism
  • Retraction push button
  • Nylon coated blade for maximum durability
  • Printed fractional graduations
  • 25” x 1″

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Thermal Camera

  • The FLIR TG165 Spot Thermal Cameras bridge the gap between single spot infrared thermometers and FLIR’s legendary thermal cameras. Equipped with FLIR’s exclusive Lepton micro thermal sensor, these cameras let you see the heat so you know exactly where to target the measurement spot. Easily find unseen hot and cold spots for instant troubleshooting, and store images and data to show others and include in reports.



Location: Engineering Circulation Desk

Thermal Camera 2

Model: Fluke Ti45

Includes:

  • Camera
  • Lens Cap
  • 2 GB CompactFlash memory card
  • CompactFlash Card Reader
  • Strap
  • Power Cable + US Plug adapter
  • 2 Batteries
  • Power Supply
  • Battery Charger
  • Video out cable
  • Owner’s Manual

The versatile choice for maintenance and production engineers and technicians. The Fluke Ti4x models feature everything needed for virtually every thermography task.

Typical applications: Predictive maintenance, Industrial maintenance, Quality control, and Process monitoring

Location: See Kari Kozak

Thermometer: Infrared

Product Description:

  • Holds temperature readings for 7 seconds
  • Wide temperature range from -40°C to 760°C (-40 °F to 1400 °F).
  • Dual displays shows current and MAX measurements simultaneously
  • Ergonomic handle with protective rubber boot

Tool Sponsor: Geb Thomas

Location: Engineering Circulation Desk

Thermometer: Wireless Probe

  • Download “Vernier Graphical Analysis” App from the App Store or Google Play and get graphical data sent directly to your smartphone.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

Programming & Circuits
Return to top of page

Circuits: Lilypad

Included:

  • 1 LilyTiny
  • 1 Battery Holder
  • 1 Battery Holder w/ Switch
  • 1 Cell Battery
  • 1 Conductive Thread
  • 1 Button Board
  • 1 Snaps
  • 1 White LED
  • 1 Green LED
  • 1 Red LED
  • 1 Blue LED
  • 1 Yellow LED
  • 1 Rainbow LED Strip
  • 1 Slide Switch
  • 2 Conductive Fabric
  • 1 Felt
  • 1 Needles

Parts are useable. Must return all containers and when returned let staff know what was used.

Guide can be found at: https://goo.gl/KEIvil

Location: Engineering Circulation Desk

Circuits: littleBits

Included:

  • 2 Power
  • 1 Light Sensor
  • 2 Slide Dimmer
  • 1 Bargraph
  • 1 Buzzer
  • 2 DC motors
  • 1 Ball Caster
  • 1 Servo and Hub
  • 1 Fan
  • 1 Wire
  • 1 Split
  • 1 Servo Mount
  • 1 Wireless Transmitter
  • 1 Wireless Receiver
  • 10 Mounting Boards
  • 2 Batteries
  • 2 Cables
  • 2 Wheels
  • 2 Motor Mates
  • 1 Screwdriver
  • 1 Mechanical Arm
  • 6 Hood and Loop Shoes
  • 5 Servo Accessories
  • 6 Adhesive Shoes
  • 2 Powersnap
  • 1 Glue Dot
  • 1 Velcro Strip
  • 9 Purple Cardboard Pieces
  • 1 Guide

Glue Dots are useable. Must return all other parts and containers. When returned let staff know what was used.

App Available in the App Store and Google Play

Guide can be found at: https://goo.gl/3tPLfM

Location: Engineering Circulation Desk

Circuits: MaKey MaKey Kit

Included:

  • 1 MaKey MaKey Board
  • 1 Mini- USB Cable
  • 29 Jumper Wires
  • 14 Alligator Clips
  • 1 Roll Copper Tape

An invention kit that encourages people to find new ways to interact with their computer

Plugs into computer and using every day conductive objects as new inputs to perform actions

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

Programming: Inventor's Kit

Included:

  • 1 RedBoard/BreadBoard/Base
  • 1 Cable
  • 1 Screwdriver
  • 1 LCD
  • 1 Servo
  • 1 Shift Resistor
  • 1 Soft Potentiometer
  • 1 Motor
  • 4 Push Buttons
  • 2 Transistors
  • 1 Temp Sensor
  • 7 Servo Parts
  • 1 Relay
  • 1 Potentiometer
  • 1 Piezo Buzzer
  • 1 Photo Resistor
  • 1 Flex Sensor
  • 1 Tri Color LED
  • 1 Diode
  • 5 Red LED
  • 5 Blue LED
  • 5 Green LED
  • 5 Yellow LED
  • 30 Wires
  • 1 330 Ohm Resistor
  • 1 10KOhm Resistor
  • 1 Guide

330 Ohm and 10KOhm Resistors are useable. Must return all other Parts and containers and when returned let staff know what was used.

Guide can be found at: https://goo.gl/76zjVb

Location: Engineering Circulation Desk

Programming: Raspberry Pi 2

  • Credit- card sized computer that plugs into a computer monitor or TV.
  • Capable of doing everything you’d expect a desktop computer to do, from browsing the internet and play high-definition video, to making spreadsheets, word- processing, and playing games.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

Programming: Raspberry Pi Starter Kit

Included:

  • 1 Raspberry Pi 3
  • 1 Pi Tin
  • 1 Pi Wedge
  • 1 Cable
  • 1 16 GB Micro SD Card and Adapter
  • 1 Power Supply
  • 1 GPIO Ribbon Cable
  • 1 BreadBoard
  • 5 Red LED
  • 5 Blue LED
  • 5 Green LED
  • 5 Yellow LED
  • 10 6” M/F Jumper Wires
  • 30 7” M/M Jumper Wires
  • 4 Push Buttons
  • 1 FTDI Basic
  • 1 MicroSD Reader
  • 1 330Ohm Resistor

330 Ohm Resistors are useable. Must return all other parts and containers and when returned.

Guide can be found at: https://goo.gl/TjQa0n

Location: Engineering Circulation Desk

Programming: RedBot

Included:

  • 1 RedBot
  • 1 Cable
  • 4 Spare Screws

Must return all parts and containers when returned.

Guide can be found at: https://goo.gl/kK3udq

Location: Engineering Circulation Desk

Vernier Interface Shield

  • A simple add-on to give your Arduino the capability to interface with Vernier sensors.
  • Attached to this interface shield are four British Telecom sockets (2 Analog, 2 Digital) which all Vernier sensors use as connectors.

Tool Sponsor: Engineering Electronics Shop

Location: Engineering Circulation Desk

Specialty Tools
Return to top of page

Calculator

TI-36X Pro

The TI-36X Pro scientific calculator is approved for use on SAT, ACT, and AP exams.

Ideal for Algebra 1 and 2, Geometry, Trigonometry, Statistics, Calculus, Biology, Chemistry, Physics, Computer Science, College math, College Science, College Engineering

Location: Engineering Circulation Desk

iPad

Apple iPad 9.7 inch

If the computer were invented today, what would it look like? It would be powerful enough for any task. So mobile you could take it everywhere. In other words, it wouldn’t really be a “computer.” It would be the new iPad.

Use it for Class, Download Apps, Explore, Learn, and create with the new iPad.

When the iPad is returned it will be factory reset so any work/apps downloaded will be deleted each time.

Specs found on Apples Website

Location: Engineering Circulation Desk

Laptop

Lenovo ThinkPad L380 Yoga has the versatility, power, and mobility to keep up – and to make your job easier. It’s ultraportable, with the latest processor and graphics, and can be used in four different modes – Laptop, Tablet, Tent, or Stand.

  • Ability to access Engineering Virtual Desktop Interface for Engineering Lab Software Load  – software such as MATLAB, Maple, and Mathematica
  • Microsoft Office Suite installed
  • Access files saved to your personal H drive
Location: Engineering Circulation Desk

PancakeBot

The PancakeBot™ is the world’s first food printer capable of printing pancakes by automatically dispensing batter directly onto a griddle. Pancake designs can be loaded onto the PancakeBot™ via SD card. Users can make their own pancake designs with the included software or browse through our online community that is updated with fun, new designs every week!

Tutorials and Guide found at http://www.pancakebot.com/

Location: See Kari Kozak

Ruler Set

Included:

  • 6 inch ruler
  • Protractor
  • Drawing Compass and Pencil
Location: Engineering Circulation Desk

White Board Markers

Includes

  • 4 dry erase markers
  • 1 eraser
  • 1 bottle of cleaner (2 oz.)
  • Do not use on cloth
  • Do not write on walls
  • Clean whiteboards after use
Location: Box 1, Box 2, Box 3,Box 4, Box 5, Box 6

VR & AR
Return to top of page

Leap Motion Controller

Included:

  • 1 Leap Motion Controller
  • 1 USB Cable

With Leap Motion, you can interact with digital content in virtual and augmented reality, Mac and PC using your hands just as you would in the real world. The unique combination of  software and hardware tracks the movement of hands and fingers with very low latency, converting it into 3D input.

Location: Engineering Circulation Desk

Leap Motion VR Dev Bundle

Included:

  • 1 Leap Motion Controller
  • 1 2-Piece Controller Mount
  • 1 15 ft USB Cable Extender,
  • 1 USB Cable

Start using your hands in VR quickly and easily with this developer bundle. Includes the Leap Motion Controller and the Universal VR Developer Mount.

Compatible with Oculus Rift

Location: Engineering Circulation Desk

Moverio

Included:

  • 1 Headset,
  • 1 Remote
  • 1 Cleaning Cloth
  • 1 Wall Adapter
  • 1 Charging Cable
  • 1 Shade Lens

MOVERIO smart glasses are setting the standard in Augmented Reality, with the smallest, most comfortable and most affordable smart eyewear on the market, combined with a growing ecosystem of partners and hardware.

Built on Android, Motion Tracking for 360° imaging, Environmental Awareness for Augmented Reality, and Dual displays for 3D Content.

Location: Engineering Circulation Desk

Oculus Rift Controllers

Oculus Rift and Sensors are set up in Creative Space at VR Station

Included:

  • 1 Oculus Remote
  • 1 Xbox One Controller
  • 1 Xbox One Controller USB Adapter
  • 1 USB Extension Cable
  • 2 Touch Controllers
  • 1 RockBand VR Attachment

Item is a 2 hour loan

Rift uses state of the art displays and optics designed specifically for VR. Its high refresh rate and low-persistence display work together with its custom  optics system to provide incredible visual fidelity and an immersive, wide field of view.

Location: Engineering Circulation Desk
